Specification
| Basic Information | |
|---|---|
| Brand | AMD |
| Model | Ryzen 5 7600X |
| Series | Ryzen 7000 Series |
| Product Type | Desktop Processor |
| Socket | AM5 |
| Cooler | Not Included |
| Processor Specifications | |
| Processor Model | AMD Ryzen 5 7600X |
| Architecture | Zen 4 |
| Manufacturing Process | TSMC 5nm FinFET |
| Cores | 6 |
| Threads | 12 |
| Base Clock | 4.7GHz |
| Max Boost Clock | Up to 5.3GHz |
| L2 Cache | 6MB |
| L3 Cache | 32MB |
| Total Cache | 38MB |
| Default TDP | 105W |
| Unlocked for Overclocking | Yes |
| Memory Specifications | |
| Memory Type | DDR5 |
| Max Memory Speed | Up to DDR5-5200 (JEDEC) |
| Memory Channels | 2 |
| ECC Memory Support | Yes (Platform Dependent) |
| Graphics Specifications | |
| Integrated Graphics | AMD Radeon Graphics |
| Graphics Cores | 2 |
| Graphics Frequency | Up to 2200MHz |
| Display Support | DisplayPort & HDMI (Motherboard Dependent) |
| Expansion Specifications | |
| PCI Express Version | PCIe 5.0 |
| PCIe Lanes | 24 PCIe 5.0 Lanes |
| Technology & Features | |
| AMD EXPO Support | Yes |
| Precision Boost 2 | Yes |
| Precision Boost Overdrive (PBO) | Yes |
| AMD Ryzen Master Support | Yes |
| AMD Virtualization (AMD-V) | Yes |
| Compatibility | |
| Supported Chipsets | X670E, X670, B650E, B650, A620 |
| Supported Operating Systems | Windows 11 (64-bit), Windows 10 (64-bit), Linux |
| Warranty Information | |
| Warranty | 3 Years Manufacturer Warranty (No Warranty for Fan or Cooler) |
