AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor

AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor

The AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor is a high-performance desktop CPU built for enthusiast gaming, content creation, streaming and demanding workloads. Based on AMD's Zen 5 architecture and featuring 2nd Gen AMD 3D V-Cache technology, it combines high clock speeds with a large cache configuration for demanding gaming and productivity applications.

12 Cores and 24 Threads

The Ryzen 9 9900X3D features 12 CPU cores and 24 processing threads with SMT support. Its 4.4GHz base clock can boost up to 5.5GHz, providing high processing capability for modern games, multitasking, streaming and content-creation workloads.

AMD 3D V-Cache Technology

One of the major highlights of the Ryzen 9 9900X3D is its large 128MB L3 cache, enabled by AMD's 3D V-Cache technology. Along with 12MB L2 cache and 960KB L1 cache, the processor provides a total cache configuration of approximately 140MB.

Zen 5 Architecture

The processor is based on AMD's Zen 5 architecture. AMD lists the CPU core manufacturing process as TSMC 4nm FinFET, while the I/O die uses TSMC 6nm FinFET technology. This architecture is designed for high-performance desktop computing across gaming and productivity workloads.

AM5 Platform and DDR5 Memory

The Ryzen 9 9900X3D uses the AM5 socket and supports DDR5 memory through two memory channels. AMD lists support for memory configurations up to DDR5-5600 depending on DIMM configuration, with ECC support available when supported by the motherboard.

PCIe 5.0 Support

For next-generation graphics and storage, the Ryzen 9 9900X3D supports PCIe 5.0 and provides 28 total native PCIe lanes, with 24 usable lanes according to AMD's specification.

Integrated AMD Radeon Graphics

The processor includes integrated AMD Radeon Graphics with 2 graphics cores running at up to 2200MHz. It also supports USB Type-C DisplayPort Alternate Mode when the motherboard provides the required implementation.

Unlocked and Tunable

The Ryzen 9 9900X3D is listed by AMD as unlocked for overclocking and supports AMD EXPO memory overclocking technology, Precision Boost Overdrive, Curve Optimizer Voltage Offsets and AMD Ryzen Master. Actual tuning capability and supported settings depend on the motherboard and system configuration.

Cooling Requirement

AMD does not include a thermal solution with the processor and recommends a liquid cooler for optimal performance. The maximum operating temperature (Tjmax) is specified at 95°C.

For users building a premium gaming PC, high-performance workstation or enthusiast AM5 desktop, the AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor offers a strong combination of Zen 5 processing performance, high clock speeds, 3D V-Cache, DDR5 memory support and PCIe 5.0 connectivity. Rose Tech & Computer can provide this processor for customers looking to build a powerful next-generation desktop system.

AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor

The AMD Ryzen 9 9900X3D is a high-performance gaming processor based on the Zen 5 architecture, which was previously known as Granite Ridge AM5. It is designed for enthusiasts, with 12 cores and 24 threads, a base frequency of 4.4 GHz, and a maximum boost rate of 5.5 GHz. The AMD Ryzen 9 9900X3D Processor is designed for gaming and multitasking, with a huge cache architecture with 960 KB of L1 cache, 12 MB of L2 cache, and an astonishing 128 MB of L3 cache. The device, built on TSMC's 4nm FinFET process for the CPU cores and a 6nm FinFET technology for the I/O die, has great power efficiency and performance with a default TDP of 120W. The AMD Ryzen 9 9900X3D Processor enables overclocking via Precision Boost Overdrive, AMD EXPO memory overclocking, and Curve Optimizer voltage offsets, making it suitable for custom tweaking. The CPU socket is AM5 and works with the A620, X670E, X670, B650E, B650, X870E, X870, B840, and B850 chipsets. The AMD Ryzen 9 9900X3D Processor supports PCIe 5.0 and has 28 total native lanes, allowing for fast GPU and NVMe storage connectivity. DDR5 memory supports a maximum capacity of 192 GB via dual memory channels. The inbuilt AMD Radeon Graphics has two cores running at 2200 MHz and compatibility for USB Type-C DisplayPort Alternate Mode. Native connectivity consists of four USB 4 (40Gbps) and one USB 3.2 Gen 1 (5Gbps) ports. The AMD Ryzen 9 9900X3D Gaming Processor can also execute AVX512, AVX2, SSE4.2, FMA3, and AES instructions.

Buy AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor from Rose Tech

In Bangladesh, you can get original AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor From Rose Tech. We have a large collection of latest AMD Processor to purchase for your Desktop PC. Order Online Or Visit your Nearest Rose Tech Shop to get yours at lowest price. The AMD Ryzen 9 9900X3D AM5 Gaming Desktop Processor comes with 03 years warranty.
